Description
Technical Specifications
- Cable Type: RG59 Coaxial with 2-Core Power (Shotgun)
- Length: 100 meters
- Resolution Support: Up to 4K (AHD, HDCVI, HD-TVI, HD-SDI)
- Impedance: 75 ohms
- Conductor: 20 AWG solid bare copper
- Shielding: 95% braided copper with AL Mylar foil
- Insulation: Foam polyethylene (PE)
- Jacket: PVC, UV-resistant, 6mm outer diameter
- Power Lead: 14/40 gauge 2-core for DC power
- Connectors: Compatible with BNC, RCA, F-Pin (sold separately)
-
Frequency Range: Up t moo 50 MHz
-
- Capacitance: 60 pF/m
- Operating Temperature: -20°C to 60°C
- Certifications: UL, CM/CL2-rated
- Warranty: 1-year limited warranty
